Lyzyc is capable of supplying angular contact ball bearing and cylindrical roller bearing for the main spindles of flat grinder and cylindrical grinder as well as motored spindles. There are a variety of configurations for customers to choose from.
| No. | Configurations | Features | Application Scope |
| 1 | Front: Angular contact ball bearing for high-speed operation (BNR and BER series) (DT) Rear: Angular contact ball bearing for high-speed operation (BNR and BER series) (DT) | High speed Low stiffness Excellent temperature rise | The spindle of machining center, grinding machine; motored spindle |
| 2 | Front: Quadruple matched bearing Rear: 2-row cylindrical roller bearing | Excellent radial and angle stiffness | The spindle of flat grinder and cylindrical grinder |
| 3 | Front: Quadruple matched angular contact ball bearing Rear: 2-row matched angular contact ball bearing | High speed High precision | The spindle of flat grinder and cylindrical grinder; ball screw support (the contact angle is 60°) |
| 4 | Front: Triple matched angular contact ball bearing Rear: Duplex matched angular contact ball bearing | High speed High precision | The spindle of machining center, CNC lathe, boring mill, internal grinding machine |
